Walrus Audio Canvas Passive Re-Amp

Canvas Passive Re-Amp

Adding another tool to the musical paint pallet, Walrus Audio is creating another way to design your tone with the Canvas Series Passive Re-Amp. The Re-Amp is a studio tool designed to send recorded guitar, drums, or other instrument tracks from your recording session through pedals and effects, or different amp combinations. The Re-Amp makes it’s appearance to facilitate all-new ways to experiment with your songs.

Adding another tool to the musical paint pallet, Walrus Audio is creating another way to design your tone with the Canvas Series Passive Re-Amp. The Re-Amp is a studio tool designed to send recorded guitar, drums, or other instrument tracks from your recording session through pedals and effects, or different amp combinations. The Re-Amp makes it’s appearance to facilitate all-new ways to experiment with your songs.

Artists and producers can save time on tracking sessions by recording dry tracks first, then using Canvas Re-Amp’s custom transformer to convert line-level signals, optimizing them to work with amps and guitar pedals of any kind to explore limitless tones and sounds.


Using a Re-Amp

1. From your DAW, audio track goes into the Canvas Re-Amp.

2. Out from Re-Amp into pedals or mic'd amp.

3. Out from pedals / amp back into DAW.

Canvas Re-Amp Features

Frequency Response : 20Hz To 20kHz
THD+N: 0.07% @ 20Hz / +4dBu Input 0.001% @ 1kHz / +4dBu Input
Maximum Input Level : +21dBu @ 20Hz
Noise Floor : -116dBu
Signal To Noise Ratio : 114dB @ 1kHz
Input : Balanced Line-Level
Input Impedance : 3k Ohms
Output : Unbalanced Instrumental-Level
Output Impedance : 2.5k Ohms
Common Mode Rejection Ratio : 79dB @ 20Hz / +4dBu Input

SPECS

Frequency Response : 20Hz To 20kHz
THD+N: 0.07% @ 20Hz / +4dBu Input 0.001% @ 1kHz / +4dBu Input
Maximum Input Level : +21dBu @ 20Hz
Noise Floor : -116dBu
Signal To Noise Ratio : 114dB @ 1kHz
Input : Balanced Line-Level
Input Impedance :  3k Ohms
Output : Unbalanced Instrumental-Level
Output Impedance : 2.5k Ohms
Common Mode Rejection Ratio : 79dB @ 20Hz / +4dBu Input
Power Requirement : None - Passive
Audio Circuit : Transformer Isolated
